PU Coated Bolt Adjustable Pipe Welding Rotator For 1000KG Job
Brief introduction:
Light duty 1000kg pipe welding rotator is produced as per usual strictly high quality production requirement. Electrics is made in accordance with CE criteria.
Feature of pipe welding rotator:
- One set pipe welding rotator is including one piece of power roller & one piece of idler roller.
- The roller center distance of pipe welding rotator can be adjusted by reserved bolt screw. Different diameter of work piece is able to use on the same rotator.
- The application of pipe welding rotator is mainly used for the seam welding.Other purpose such as job positioning rotationg likewise is also applicable.
Other Models Technical Parameters:
| Type | Max. load (Ton) | suitable size of job (mm) | Wheel diameter and width (mm) | Motor power (Kw) |
| HGKS 5 | 5 | Φ250-2300 | Φ250×100 | 2×0.37 |
| HGKS10 | 10 | Φ320-2800 | Φ300×120 | 2×0.55 |
| HGKS20 | 20 | Φ500-3500 | Φ350×120 | 2×1.1 |
| HGKS40 | 40 | Φ600-4200 | Φ400×120 | 2×1.5 |
| HGKS60 | 60 | Φ750-4800 | Φ450×120 | 2×2.2 |
| HGKS80 | 80 | Φ850-5000 | Φ500×120 | 2×2.2 |
| HGKS100 | 100 | Φ1000-5500 | Φ500×120 | 2×2.2 |
Pipe welding rotator description:
- The pipe welding rotator series have a strong and durable construction, by which creates a very high stability.
- The steel wheel of welding rotator enclosed lock solid PU tyres.
- The electronic components of the pipe welding rotators are top class. It is equipped with stepless adjustable speed control. All electrics with CE marked.
- The production is according with mechanical standard JB/T 9187-1999.
- The favourable price performance ratio yields will ensure a quick payback of your investment.
- We also provide tailor-made pipe welding rotator according to your special requirements.
Certification:
Welding rotator CE certification.pdf
Exhibition photo:
Points you may concern:
- Customization - Can your machine or other products be customized?
- Ronniewell: Sure. As a professional manufacturer, we have our own engineer team, who is good at design, develop & build special solution catering for your individual requirement.
- Transportation-What about the transportation?
- Ronniewell: Seaway is the most common transportation way for oversea trading. Depends on your location, combined transport by rail and sea is also an option. Certainly railway transportation is also acceptable if it is the most suitable approach.
- After sale service - What about the after-sale service?
- Ronniewell: We provide 12month guaranty period for the whole machine quality. During this time, any issue proved because of the machine flaw itself,we would take the whole responsibility of it. Except of the guaranty period,technical advisory support is available freely covering the whole using life of the machine. Engineer service on user premises is also available for necessary.
Name of the machine:
welding rotator, pipe welding rotator, pipe turning rolls, welding turning rolls, welding roller, tank turning rolls, pipe turning rolls, tube turning rolls, fit up rotator, self-aligned welding rotator, self-aligning welding rotator, self adjustable welding rotator, self aligned roller stand, wheel frame, roller frame for wind tower welding, automatic adjustable welding pipe rotator, pipe welding rotator, bolt adjustable welding rotator, sand blasting rotator, painting rotator, 1+1 hydraulic fit up rotator, two in one fit up station
